Main Specifications of 45 Gallon Chemical Storage Cabinets

SSM100045P-Waste storage Cabinets
45-gallon
1 Shelf (Adjustable)
1 door, Manual - Can choose self-locking
Ext. Sizes H*W*D(mm/in): 1650×1090×460mm/ 65×43×18 in
Int. Sizes H*W*D(mm/in): 1550×1010×380mm/ 61×40×15 in
Weight: 138Kgs/ 304 lbs

1. Cabinet Size:1090mm(W)x460mm(D)x1650mm(H)
2. Material: Sturdy 1.2mm(16 gauge) double walled steel with 40mm(1.5'') of insulating air space
3. Material Thickness:1.2mm
4. All cabinets built to comply with FM, OSHA
5. Designed to storage all Class 3 liquids
6. Distinct safety signs and directions.
7. Highly visible warning label" Flammable-Keep Fire Away".
8. All welded construction versus spot welded construction.
9. Durable and chemical resistant, powder coat paint finish, inside and outside
10. Retains high gloss look and minimizes the effect of corrosion and humidity.
11. Dual vents with built-in flash arresters strategically placed at bottom and opposite top.
12. Liquid-tight containment sump.
13. Continuous piano hinge doors to open 180 degree
14. 50mm (2'') leak-proof sump to contain spills.
15. Zinc steel shelves are adjustable on 55mm(2.2'') space for versatile storage.
16. Dual vents with built-in flash arresters strategically placed at bottom and opposite top.
17. Welded shelf hangers interlock with shelf to offer maximum "no slip" stability and no flimsy bracket to lose.
18. Earthing point to guard against static electricity dischange.
19. Three-point mutual locking system with high-strength stainless steel bullet latches
20. Exclusive paddle lock for extra security. Two keys lockable.
21. Minimal air-gaps provide better protection.

Market Segments

•  Charter Schools
• Higher Education - University, CollegesF
• ood Beverage facilities
• Life Science
• Bio-Technology
• Industrial Research & Development
• Medical research
• Water treatment Plants




  Model	Door Types	Description	Overall Size H×W×D(mm)	Overall Size H×W×D(inch)	Capacity (gal/L)	Numbe of shelf(pcs)	N.W. (kg)
  SSM100004	Manual	Under-Bench cabinet with 1 door	560×430×430	22×17×17	4/15	1	34
  SSM100012	Manual	Under-Bench cabinet with 1 door	890×590×460	35×23×18	12/45	1	60
  SSM100015	Manual	Under-Bench cabinet with 1 door	1120×590×460	44×23×18	15/57	1	66
  SSM101015	Manual	Under-Bench cabinet with 1 door	910×610×550	36×24×22	15/57	1	65
  SSM100016	Manual	Under-Bench cabinet with 1 door	1120×610×460	44×24×18	16/61	1	68
  SSM100017	Manual	Working cover cabinet with 2 doors	610×1090×460	24×43×18	17/64	1	70
  SSM100019	Manual	Under-Bench cabinet with 1 door	910×760×550	36×30×22	19/72	1	68
  SSM100020	Manual	Under-Bench cabinet with 1 door	1120×590×460	44×23×18	20/76	1	66
  SSM101020	Manual	Under-Bench cabinet with 2 doors	1120×1090×300	44×43×12	20/76	1	66
  SSM100022	Manual	Vertical cabinet with 1 doors	1650×590×460	65×23×18	22/83	2	90
  SSM101023	Manual	Under-Bench cabinet with 1 door	910×920×550	36×36×22	23/87	1	66
  SSM101030	Manual	Working cover cabinet with 2 doors	890×910×610	35×36×24	30/114	1	100
  SSM100030	Manual	Working cover cabinet with 2 doors	1120×1090×460	44×43×18	30/114	1	100
  SSM100031	Manual	Under-Bench cabinet with 1 door	910×1220×550	36×43×18	31/117	1	105
  SSM100040	Manual	Working cover cabinet with 2 doors	1120×1090×460	44×43×18	40/151	3	100
  SSM100045	Manual	Tall cabinet with 2 doors	1650×1090×460	65×43×18	45/170	2	138
  SSM100054	Manual	Tall cabinet with 2 doors	1650×600×870	65×24×34	54/204	3	148
  SSM100060	Manual	Tall cabinet with 2 doors	1650×860×860	65×34×34	60/227	2	165
  SSM100090	Manual	Tall cabinet with 2 doors	1650×1090×860	65×43×34	90/340	2	190
